- 价格 : ￥1000.00/台
- 品牌 : KEST
- 制动力 : 670-3550N
- 气压 : 6bar
- 盘径 : 可订制
- 起订 : 5台
- 供应 : 500台
技术数据
制动力F：
KB3-1 670 N 6bar
KB3-2 1800 N 6bar
KB3-3 3550 N 6bar
加速力矩
=F*[制动盘半径(m)-0.032]=Nm
**总磨损: 14 mm
新摩擦片厚度: 16 mm
持续滑动时的热容量Qc: 1.7 kW
双倍制动垫型持续滑动时的热容量
Qc: 2.7 kW
Technical data
Braking force F:
KB3-1 670 N at 6 bar
KB3-2 1800 N at 6 bar
KB3-3 3550 N at 6 bar
Dynamic torque
= F*(disc radius in m - 0.032) = Nm
Max total wear: 14 mm
Thickness of new lining: 16 mm
Continuous thermal capacity
Qc: 1.7 kW
Continuous thermal capacity
for double pad version Qc: 2.7 kW
技术数据
制动力F：
KBS3-1 1300 N
KBS3-2 2600 N
动态力矩
=F*[制动盘半径(m)-0.032]=Nm
**总磨损: 14 mm
新摩擦片厚度: 16 mm
持续滑动时的热容量Qc: 1.7 kW
双衬垫型持续滑动时的热容量Qc: 2.7 kW
松钳**小气压: 5 bar
图表显示数据依据如下条件:
3-1装有4根弹簧
3-2和3-3装有8根弹簧
若要减少力矩值可相应地减少弹簧数量：
3-1 2根弹簧
3-2和3-3 6、4、2根弹簧
图表指示了每两毫米摩擦片磨损的力矩变
化情况。
如需恢复到相应额定力矩，请按照使用手册
说明进行调整。
Technical data
Braking force F:
KBS3-1 1300 N
KBS3-2 2600 N
Dynamic torque
= F*(disc radius in m - 0.032) = Nm
Max total wear: 14 mm
Thickness of new lining: 16 mm
Continuous thermal capacity Qc: 1.7 kW
Continuous thermal capacity
for double pad version Qc: 2.7 kW
Minimum release pressure: 5 bar
The torque values specified
are obtained with n. 4 springs for 13-1,
n. 8 springs for 3-2 and 3-3.
Torque proportionally less
are achievable with n. 2 springs for 3-1,
n. 6-4-2 springs for 3-2 and 3-3.
The diagram shows the torque
variation for 2 millimeters of lining wear.
Adjust according to ensure the
correct torque value is achieved.
